SureFast Coated Ball Lock Stainless Steel Cable Ties SureFast Coated Ball Lock Stainless Steel Cable Ties SureFast Coated Ball Lock Stainless Steel Cable Ties

SureFast Coated Ball Lock Stainless Steel Cable Ties

Our SureFast Coated Ball Lock Stainless Steel Cable Ties are well known for their strength, durability and corrosion resistance. These Cable Ties have all the same advantageous properties as the uncoated variant but have added protection from the pure polyester and epoxy coating. This coating adds an extra layer of protection against highly corrosive environments. These Stainless Steel Cable Ties are also certified, meaning they can be used in major engineering projects, so you can expect nothing less than premium quality.
  • Available for export available for export

Key product features

SureFast Coated Stainless Steel Ball Lock Cable Ties

About Coated SureFast Stainless Steel Cable Ties

Our SureFast Ball Lock Stainless Steel Cable Ties are made from high-quality Stainless Steel which is ideal for demanding environments that require high strength and reliability, perfect for the chemical, oil and gas, shipbuilding and mining industries.

There is a steel ball positioned inside the head of each cable tie which allows it to lock into place at any length along the tie. They have round edges and smooth surfaces which incorporate fast, safe hand installation, with the tail of the cable tie also being angled for an easier connection.

An advantage of these Stainless Steel Cable Ties is that they have a fully enclosed head that does not allow dirt or grit to interfere with the locking mechanism. This particular variant also has a pure polyester and epoxy coating which adds an added layer of protection against highly corrosive environments.

SureFast Ball Lock Stainless Steel Cable Ties prevent corrosion between dissimilar metals.

Resistance

  • Corrosion
  • Vibration
  • Radiation
  • Extreme Temperature

Where are cable ties used?

  • Cable bundling
  • Sign Mounting
  • Post Mounting
  • Exhaust Pipes

Technical Information

  • 304 & 316 Grade non-magnetic Stainless Steel
  • Temperature Range of -80C > +150C
  • Pure Polyester & Epoxy Coating Surface Finish
  • Non-Toxic
  • Halogen Free
  • Fireproof
  • UV resistant

Ball Lock Coated, 304 Stainless Steel, 4.6mm width


Reference Material Width Length Thickness Max Diameter Single Loop Minimum Loop Tensile Strength Package Quantity
SF2798-CTD 304 Stainless Steel 0.18" / 4.6mm 4" / 100mm 0.01" / 0.25mm 1.1" / 27mm 667N / 150lbs 100 per bag
SF2799-CTD 304 Stainless Steel 0.18" / 4.6mm 6" / 150mm 0.01" / 0.25mm 1.7" / 43mm 667N / 150lbs 100 per bag
SF2800-CTD 304 Stainless Steel 0.18" / 4.6mm 8" / 200mm 0.01" / 0.25mm 2.3" / 59mm 667N / 150lbs 100 per bag
SF2801-CTD 304 Stainless Steel 0.18" / 4.6mm 10" / 260mm 0.01" / 0.25mm 3.1" / 78mm 667N / 150lbs 100 per bag
SF2802-CTD 304 Stainless Steel 0.18" / 4.6mm 14" / 360mm<t/d> 0.01" / 0.25mm 4.3" / 110mm 667N / 150lbs 100 per bag
SF2803-CTD 304 Stainless Steel 0.18" / 4.6mm 20" / 520mm 0.01" / 0.25mm 6.3" / 161mm 667N / 150lbs 100 per bag
SF2804-CTD 304 Stainless Steel 0.18" / 4.6mm 24" / 620mm 0.01" / 0.25mm 7.6" / 192mm 667N / 150lbs 100 per bag
SF2805-CTD 304 Stainless Steel 0.18" / 4.6mm 33" / 840mm 0.01" / 0.25mm 10.4" / 263mm 667N / 150lbs 100 per bag
SF2806-CTD 304 Stainless Steel 0.18" / 4.6mm 39" / 1000mm 0.01" / 0.25mm 12.3" / 313mm 667N / 150lbs 100 per bag

Ball Lock Coated, 316 Stainless Steel, 4.6mm width


Reference Material Width Length Thickness Max Diameter Single Loop Minimum Loop Tensile Strength Package Quantity
SF2818-CTD 316 Stainless Steel 0.18" / 4.6mm 4" / 100mm 0.01" / 0.25mm 1.1" / 27mm 667N / 150lbs 100 per bag
SF2819-CTD 316 Stainless Steel 0.18" / 4.6mm 6" / 150mm 0.01" / 0.25mm 1.7" / 43mm 667N / 150lbs 100 per bag
SF2820-CTD 316 Stainless Steel 0.18" / 4.6mm 8" / 200mm 0.01" / 0.25mm 2.3" / 59mm 667N / 150lbs 100 per bag
SF2821-CTD 316 Stainless Steel 0.18" / 4.6mm 10" / 260mm 0.01" / 0.25mm 3.1" / 78mm 667N / 150lbs 100 per bag
SF2822-CTD 316 Stainless Steel 0.18" / 4.6mm 14" / 360mm<t/d> 0.01" / 0.25mm 4.3" / 110mm 667N / 150lbs 100 per bag
SF2823-CTD 316 Stainless Steel 0.18" / 4.6mm 20" / 520mm 0.01" / 0.25mm 6.3" / 161mm 667N / 150lbs 100 per bag
SF2824-CTD 316 Stainless Steel 0.18" / 4.6mm 24" / 620mm 0.01" / 0.25mm 7.6" / 192mm 667N / 150lbs 100 per bag
SF2825-CTD 316 Stainless Steel 0.18" / 4.6mm 33" / 840mm 0.01" / 0.25mm 10.4" / 263mm 667N / 150lbs 100 per bag
SF2826-CTD 316 Stainless Steel 0.18" / 4.6mm 39" / 1000mm 0.01" / 0.25mm 12.3" / 313mm 667N / 150lbs 100 per bag

Ball Lock Coated, 304 Stainless Steel, 7.9mm width


Reference Material Width Length Thickness Max Diameter Single Loop Minimum Loop Tensile Strength Package Quantity
SF2807-CTD 304 Stainless Steel 0.31" / 7.9mm 4" / 100mm 0.01" / 0.25mm 1.1" / 27mm 1335N / 300lbs 100 per bag
SF2808-CTD 304 Stainless Steel 0.31" / 7.9mm 6" / 150mm 0.01" / 0.25mm 1.7" / 43mm 1335N / 300lbs 100 per bag
SF2809-CTD 304 Stainless Steel 0.31" / 7.9mm 8" / 200mm 0.01" / 0.25mm 2.3" / 59mm 1335N / 300lbs 100 per bag
SF2810-CTD 304 Stainless Steel 0.31" / 7.9mm 10" / 260mm 0.01" / 0.25mm 3.1" / 78mm 1335N / 300lbs 100 per bag
SF2811-CTD 304 Stainless Steel 0.31" / 7.9mm 14" / 360mm<t/d> 0.01" / 0.25mm 4.3" / 110mm 1335N / 300lbs 100 per bag
SF2812-CTD 304 Stainless Steel 0.31" / 7.9mm 20" / 520mm 0.01" / 0.25mm 6.3" / 161mm 1335N / 300lbs 100 per bag
SF2813-CTD 304 Stainless Steel 0.31" / 7.9mm 24" / 620mm 0.01" / 0.25mm 7.6" / 192mm 1335N / 300lbs 100 per bag
SF2814-CTD 304 Stainless Steel 0.31" / 7.9mm 33" / 840mm 0.01" / 0.25mm 10.4" / 263mm 1335N / 300lbs 100 per bag
SF2815-CTD 304 Stainless Steel   39" / 1000mm 0.01" / 0.25mm 12.3" / 313mm 1335N / 300lbs 100 per bag

Ball Lock Coated, 316 Stainless Steel, 7.9mm width


Reference Material Width Length Thickness Max Diameter Single Loop Minimum Loop Tensile Strength Package Quantity
SF2827-CTD 316 Stainless Steel 0.31" / 7.9mm 4" / 100mm 0.01" / 0.25mm 1.1" / 27mm 1335N / 300lbs 100 per bag
SF2828-CTD 316 Stainless Steel 0.31" / 7.9mm 6" / 150mm 0.01" / 0.25mm 1.7" / 43mm 1335N / 300lbs 100 per bag
SF2829-CTD 316 Stainless Steel 0.31" / 7.9mm 8" / 200mm 0.01" / 0.25mm 2.3" / 59mm 1335N / 300lbs 100 per bag
SF2830-CTD 316 Stainless Steel 0.31" / 7.9mm 10" / 260mm 0.01" / 0.25mm 3.1" / 78mm 1335N / 300lbs 100 per bag
SF2831-CTD 316 Stainless Steel 0.31" / 7.9mm 14" / 360mm<t/d> 0.01" / 0.25mm 4.3" / 110mm 1335N / 300lbs 100 per bag
SF2832-CTD 316 Stainless Steel 0.31" / 7.9mm 20" / 520mm 0.01" / 0.25mm 6.3" / 161mm 1335N / 300lbs 100 per bag
SF2833-CTD 316 Stainless Steel 0.31" / 7.9mm 24" / 620mm 0.01" / 0.25mm 7.6" / 192mm 1335N / 300lbs 100 per bag
SF2834-CTD 316 Stainless Steel 0.31" / 7.9mm 33" / 840mm 0.01" / 0.25mm 10.4" / 263mm 1335N / 300lbs 100 per bag
SF2835-CTD 316 Stainless Steel 0.31" / 7.9mm 39" / 1000mm 0.01" / 0.25mm 12.3" / 313mm 1335N / 300lbs 100 per bag

Ball Lock Coated, 304 Stainless Steel, 12.7mm width


Reference Material Width Length Thickness Max Diameter Single Loop Minimum Loop Tensile Strength Package Quantity
?????? 304 Stainless Steel 0.50" / 12.7mm 4" / 100mm 0.01" / 0.25mm 1.1" / 27mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 6" / 150mm 0.02" / 0.40mm 1.7" / 43mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 8" / 200mm 0.02" / 0.40mm 2.3" / 59mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 10" / 260mm 0.02" / 0.40mm 3.1" / 78mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 14" / 360mm<t/d> 0.02" / 0.40mm 4.3" / 110mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 20" / 520mm 0.02" / 0.40mm 6.3" / 161mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 24" / 620mm 0.02" / 0.40mm 7.6" / 192mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 33" / 840mm 0.02" / 0.40mm 10.4" / 263mm 3115N / 700lbs 100 per bag
?????? 304 Stainless Steel 0.50" / 12.7mm 39" / 1000mm 0.02" / 0.40mm 12.3" / 313mm 3115N / 700lbs 100 per bag

Ball Lock Coated, 316 Stainless Steel, 12.7mm width


Reference Material Width Length Thickness Max Diameter Single Loop Minimum Loop Tensile Strength Package Quantity
SF2848-CTD 316 Stainless Steel 0.50" / 12.7mm 6" / 150mm 0.02" / 0.40mm 1.7" / 43mm 3115N / 700lbs 100 per bag
SF2849-CTD 316 Stainless Steel 0.50" / 12.7mm 8" / 200mm 0.02" / 0.40mm 2.3" / 59mm 3115N / 700lbs 100 per bag
SF2850-CTD 316 Stainless Steel 0.50" / 12.7mm 10" / 260mm 0.02" / 0.40mm 3.1" / 78mm 3115N / 700lbs 100 per bag
SF2851-CTD 316 Stainless Steel 0.50" / 12.7mm 14" / 360mm<t/d> 0.02" / 0.40mm 4.3" / 110mm 3115N / 700lbs 100 per bag
SF2852-CTD 316 Stainless Steel 0.50" / 12.7mm 20" / 520mm 0.02" / 0.40mm 6.3" / 161mm 3115N / 700lbs 100 per bag
SF2853-CTD 316 Stainless Steel 0.50" / 12.7mm 24" / 620mm 0.02" / 0.40mm 7.6" / 192mm 3115N / 700lbs 100 per bag
SF2854-CTD 316 Stainless Steel 0.50" / 12.7mm 33" / 840mm 0.02" / 0.40mm 10.4" / 263mm 3115N / 700lbs 100 per bag
SF2855-CTD 316 Stainless Steel 0.50" / 12.7mm 39" / 1000mm 0.02" / 0.40mm 12.3" / 313mm 3115N / 700lbs 100 per bag
